Custom CNC Titanium Alloy Grade 9 Ti-3Al-2.5V UNS R56320 Machining Parts

Qualify Evaluation Report

For each order we receive, we can provide a list of quality inspection reports according to your processing requirements.

Inspection  report
Full dimension report
Material Test Report

Certificate

As an experienced manufacturer of on-demand CNC machined parts, has obtained the following certifications.

ISO 9001:2015

IATF 16949:2015

ROHS Directive

12 patent certifications

More Details>>

What is Titanium Alloy Grade 9 (Ti-3Al-2.5V UNS R56320)?

Titanium Grade 9 (Ti-3Al-2.5V) is an alpha-beta titanium alloy composed of 3% aluminum (Al), 2.5% vanadium (V), and the balance titanium. It is known for its high strength, light weight, excellent corrosion resistance, and good weldability. Grade 9 is often used in applications that require a combination of good strength and moderate formability.

What are the advantages of using Ti-3Al-2.5V alloy for CNC machining?

Ti-3Al-2.5V offers a higher strength-to-weight ratio compared to pure titanium. It is also more formable and easier to weld than other titanium alloys, such as Ti-6Al-4V. This alloy provides excellent resistance to corrosion, making it suitable for use in harsh environments. It’s also relatively easier to machine compared to other high-strength titanium alloys.

What are the typical applications for Ti-3Al-2.5V alloy?

Ti-3Al-2.5V is commonly used in aerospace, marine, chemical processing, and medical industries. Applications include aircraft structural components, airframe parts, pressure vessels, surgical instruments, and marine hardware. Its light weight and strength make it ideal for demanding industries that require materials with excellent performance in challenging environments.

How is CNC machining of Ti-3Al-2.5V alloy performed?

CNC machining of Ti-3Al-2.5V alloy typically involves processes such as turning, milling, drilling, and grinding. Specialized carbide tools are often used due to the material’s hardness. Proper cutting parameters, including feeds, speeds, and coolant application, are crucial to avoid overheating, tool wear, and surface finish issues. The alloy’s lower thermal conductivity means that heat is concentrated at the cutting edge, requiring effective cooling methods.

What are the challenges when machining Ti-3Al-2.5V alloy?

Machining Ti-3Al-2.5V can be challenging due to the alloy’s tendency to work-harden during cutting. This requires using sharp tooling and maintaining optimal cutting speeds to reduce tool wear. The material’s low thermal conductivity also means that heat can build up during machining, which can cause material deformation or tool damage if not properly managed. Therefore, controlling the cutting environment and using suitable coolant is crucial.

How does Ti-3Al-2.5V compare to other titanium alloys?

Compared to Ti-6Al-4V, Ti-3Al-2.5V has lower strength but is more formable and easier to weld. It has a lower alpha-beta transition temperature and is less sensitive to heat treatment. This makes Ti-3Al-2.5V a good option for applications that require moderate strength but easier handling and fabrication. While Ti-6Al-4V offers superior strength for high-performance applications, Ti-3Al-2.5V offers a better balance of workability and strength for many industrial uses.

What is the corrosion resistance of Ti-3Al-2.5V?

Ti-3Al-2.5V has excellent corrosion resistance, especially in environments like seawater, chlorine, and other corrosive media. It resists attack from a wide variety of acids and is highly resistant to pitting, crevice, and stress corrosion. This makes Ti-3Al-2.5V a popular choice in marine, chemical, and industrial applications where exposure to harsh chemicals and environments is common.

Can Ti-3Al-2.5V be welded?

Yes, Ti-3Al-2.5V is a weldable alloy, and its weldability is better than that of higher-strength titanium alloys, like Ti-6Al-4V. Common welding methods include TIG (Tungsten Inert Gas) welding, MIG (Metal Inert Gas) welding, and resistance welding. However, welding titanium requires careful control of the heat input, shielding gas, and material cleanliness to prevent contamination and defects.

What is the typical lead time for custom CNC machining of Ti-3Al-2.5V alloy parts?

The lead time for custom CNC machining of Ti-3Al-2.5V alloy parts depends on factors such as the complexity of the part, the volume of production, and machine availability. Typically, small to medium batch production can take anywhere from a few days to several weeks. For large orders or highly complex parts, the lead time may extend depending on the specific machining and finishing requirements.

What is the cost comparison between Ti-3Al-2.5V and other titanium alloys?

Ti-3Al-2.5V is typically more affordable than high-strength alloys like Ti-6Al-4V, making it a cost-effective choice for many applications that don’t require the highest strength. However, it is more expensive than other materials like aluminum and steel. The price of Ti-3Al-2.5V also depends on the market conditions and specific suppliers.
